SmartPro 230V 3kVA 2.25kW Line‑Interactive UPS (SMARTINT3000VS)

SmartPro 230V 3kVA 2.25kW Line-Interactive UPS, Tower, Extended Run, Network Card Options, USB, DB9 Serial 14 minutes half load runtime and 4 minutes at full load, PDU Integration Capability, Expandable Runtime

Description

The SmartPro 230V 3kVA Line-Interactive UPS is a high-capacity power protection solution designed for servers, networking equipment, and critical IT infrastructure. It provides 3000VA/2250W of backup power with automatic voltage regulation to protect against blackouts, brownouts, and surges while maintaining stable output. The built-in batteries deliver approximately 14 minutes runtime at half load and 4 minutes at full load, and runtime can be extended using external battery packs for longer operation.

This UPS also supports network management card options, USB and DB9 communication ports, and PDU integration capability, making it ideal for remote monitoring and scalable deployment in business environments.

Key Specifications

• Capacity: 3000VA / 2250W
• Topology: Line-Interactive
• Input Voltage: 230V nominal
• Runtime: 14 minutes (half load), 4 minutes (full load)
• Form Factor: Tower
• Communication Ports: USB & DB9 Serial
• Network Card Slot: Yes (optional)
• Runtime Expansion: External battery pack support
• Output Control: Multiple load banks
• Integration: PDU compatibility
• Protection: Surge, brownout, overvoltage

Features

• High Power Capacity (3kVA / 2.25kW) – Supports multiple servers, switches, and network devices simultaneously.
• Extended Runtime Capability – External battery packs can be added to increase backup duration for critical loads.
• Automatic Voltage Regulation (AVR) – Stabilizes voltage without switching to battery, improving battery life.
• Network Card Options – Enables remote monitoring and management via SNMP or web interface.
• USB & DB9 Communication Ports – Allows unattended shutdown and monitoring using UPS software.
• PDU Integration Capability – Works with bypass PDUs for maintenance without interrupting connected equipment.
• Expandable Runtime Design – Scales easily for growing IT infrastructure.
• Multiple Load Banks – Allows selective reboot or load shedding to extend runtime for critical devices.

Applications

• Server rooms
• Network racks
• Data centers
• Telecom equipment
• Security systems
• Corporate IT infrastructure
• Industrial automation systems
