Eaton 5E Gen2 700VA/360W USB UPS IEC (5E700B)

The Eaton 5E Gen2 700VA/360W USB UPS (IEC) is a compact line-interactive uninterruptible power supply (UPS) designed to protect computers and small office equipment from power cuts, voltage fluctuations, and surges. It provides short-term battery backup so you can safely save work and shut down devices during outages.

Built with Automatic Voltage Regulation (AVR), it stabilizes incoming power without switching to battery during minor fluctuations, helping extend battery life. It is ideal for home offices, small businesses, routers, PCs, and NAS systems that need reliable and quiet power protection in a small footprint.

This UPS is part of Eaton’s 5E Gen2 series, known for affordability, efficiency, and ease of use with plug-and-play USB connectivity for automatic system shutdown.

Specifications

• Model: Eaton 5E Gen2 700VA USB IEC
• Capacity: 700VA / 360W
• Topology: Line-interactive
• Input Voltage: 220–240V AC
• Output Voltage: 230V AC
• Output Waveform: Simulated sine wave
• Automatic Voltage Regulation (AVR): Yes
• Outlets: 4 × IEC C13 sockets
• Communication Port: USB (HID compatible)
• Battery Type: Sealed lead-acid (12V / 7Ah)
• Typical Backup Time: 10–15 minutes (depends on load)
• Recharge Time: Approx. 6–8 hours to 90%
• Cold Start Function: Supported
• Auto Restart: Supported
• Noise Level: Low (fanless operation under normal use)
• Dimensions: Approx. 288 × 148 × 100 mm
• Weight: Approx. 4.2–4.4 kg
• Installation Type: Tower (standalone)

Features

1. Line-Interactive Technology with AVR

The UPS uses line-interactive technology combined with Automatic Voltage Regulation (AVR) to stabilize incoming power. This means it can correct small voltage fluctuations such as low or high voltage without switching to battery mode, helping protect connected devices while extending battery lifespan.

2. Reliable Battery Backup

When a power outage occurs, the UPS instantly switches to battery power to keep your devices running. This provides enough time to save important work, safely shut down computers, and prevent data loss or hardware damage caused by sudden power failure.

3. USB Communication for Auto Shutdown

The built-in USB port allows the UPS to communicate with a computer or server. When power is critically low, it can automatically trigger a safe shutdown process, protecting your system from abrupt power loss without requiring manual intervention.

4. Quiet and Fanless Operation

The Eaton 5E Gen2 operates silently under normal conditions because it does not use a cooling fan. This makes it ideal for quiet environments such as home offices, study rooms, or reception areas where noise reduction is important.

5. Cold Start Capability

This UPS can power connected devices even when there is no mains electricity available. This feature, known as cold start, allows users to temporarily run essential equipment directly from the battery during a blackout.

6. Automatic Restart Function

Once power is restored, the UPS automatically restarts itself and continues supplying power to connected devices. This ensures minimal downtime and allows systems like routers, PCs, or POS machines to resume operation without manual setup.

7. Compact and Space-Saving Design

The UPS is designed in a compact tower form, making it easy to place under desks or in tight office spaces. Its lightweight structure also makes it simple to install and move when needed.

8. Device Protection Against Power Issues

It provides protection against power surges, spikes, and voltage drops that can damage sensitive electronics. This ensures stable and clean power delivery, improving the lifespan and reliability of connected equipment.

Applications

• Desktop Computers & Workstations
  The UPS is commonly used to support desktop PCs and office workstations, ensuring users can continue working briefly during power outages and safely shut down systems to avoid data loss or system corruption.
• Home & Small Office Networks (Routers & Modems)
  It is ideal for keeping internet routers, modems, and small network devices powered during blackouts, helping maintain internet connectivity for remote work, online classes, and communication.
• NAS (Network Attached Storage) Systems
  The UPS provides backup power to NAS devices, ensuring that stored data remains protected and that systems can shut down safely to prevent file corruption during sudden power interruptions.
• CCTV Surveillance Systems (DVR/NVR)
  It is widely used in security setups to keep CCTV DVRs and NVRs running during power failures, ensuring continuous recording and monitoring for security purposes.
• Point of Sale (POS) Systems
  Retail shops, supermarkets, and small businesses use this UPS to keep POS machines running, preventing transaction interruptions and system downtime during outages.
• Home Office Setups
  For remote workers and freelancers, it supports essential devices like PCs, routers, and monitors, ensuring productivity is not affected by unstable power supply.
• Small Business Equipment
  It is suitable for protecting basic office equipment such as small printers, switches, and communication devices that require stable and uninterrupted power.
• Educational and Study Environments
  Students and learning institutions use it to protect computers and study equipment, allowing safe saving of work and uninterrupted learning sessions during power cuts.
