16-Port Console Server with USB – Built-In Modem, Dual GbE NIC, 16 Gb Flash, 1U Rack, TAA

16-Port Console Server with USB – Built-In Modem, Dual GbE NIC, 16 Gb Flash, 1U Rack, TAA

Overview
The Tripp Lite B098-016 16‑Port Console Server is a secure remote-management solution designed to control and monitor multiple serial and network devices from a single platform. It features 16 RJ-45 console ports, dual Gigabit Ethernet interfaces, built-in modem access, and 16 GB flash storage in a compact 1U rack-mountable form factor. This console server enables reliable in-band and out-of-band access to routers, switches, firewalls, PDUs, and other infrastructure equipment.

Key Features

• 16 Serial Console Ports – Manage up to 16 devices simultaneously via standard Cat5e/6 cabling.
• Built-In V.92 Modem – Provides out-of-band dial-up access during network outages.
• Dual Gigabit Ethernet NICs – Offers primary connection with automatic failover for high availability.
• 16 GB Internal Flash Memory – Stores logs and configuration files; expandable using an SD card.
• USB Console Ports – Connect newer USB-based devices such as PDUs and UPS systems.
• Advanced Security Support – Includes SSL/SSH, VPN, firewall, and authentication via LDAP, RADIUS, and TACACS+.
• 1U Rack-Mount Design – Steel housing fits standard 19-inch racks for data-center deployment.
• TAA-Compliant – Suitable for government and regulated procurement environments.

Specifications

• Ports: 16 x RJ-45 Serial Console
• Network Interfaces: Dual Gigabit Ethernet
• USB Ports: 2 x USB 2.0 console
• Modem: Built-in V.92 for out-of-band access
• Flash Memory: 16 GB internal NAND (SD expandable)
• Mounting: 1U Rack-mount / desktop option
• Security: SSH, SSL, VPN, firewall, directory authentication
• Compliance: TAA compliant
• Application: Remote device management & network monitoring

Applications / Use Cases

• Data center infrastructure management
• Remote branch office monitoring
• Network operations centers (NOC)
• Telecom and ISP deployments
• Industrial and edge networking environments
• Remote troubleshooting during outages

Why Choose This Console Server

• Enables centralized control of multiple serial devices
• Provides reliable failover with dual Ethernet ports
• Maintains remote access even when network fails
• Offers strong security for sensitive infrastructure
• Saves time and cost by eliminating on-site visits
