Eaton 9355 UPS

GENERAL
DIAGNOSTICS	Full system self-test at startup
UPS BYPASS	Automatic on overload or UPS failure
PARALLEL FOR REDUNDANCY	Yes, using Powerware Hot Sync technology and capacity
DIMENSIONS AND WEIGHTS	See product brochure
OVERLOAD (NORMAL OPERATION)	150% for 5 sec / 125% for 1 min (online), 110% for 10 min
ELECTRICAL INPUT
NOMINAL INPUT VOLTAGE	9355 (10 – 15 kVA): 208V/120V or 220V/127V three-phase 400V models also available	9355 (20 – 30 kVA): 208V/120V, 220V/127V +10, -15% 480V/277V, 600V (480+600 with transformer) 400V models also available
INPUT VOLTAGE RANGE	-15%, +10% from nominal at 100% load without depleting battery
OPERATING FREQUENCY	50/60 Hz (45 to 65 Hz)
INPUT POWER FACTOR	9355 (10 – 15 kVA): >0.99 typical, >0.96 frequency converter	9355 (20 – 30 kVA): 0.99 typical
INPUT CURRENT DISTORTION	5% THD
ELECTRICAL OUTPUT
NOMINAL OUTPUT VOLTAGE	9355 (10 – 15 kVA): 208/120, 220/127 Vac	9355 (20 – 30 kVA): 208/120, 220/120 Vac
OUTPUT VOLTAGE REGULATION	9355 (10 – 15 kVA): ±1% static; ±5% dynamic at 100% resistive load change, <1 ms response time	9355 (20 – 30 kVA): ±1% static; ±4% dynamic with 100% step load recovery within 1 ms response time
EFFICIENCY	91%, typical
HEAT DISSIPATION (BTU/HR)	10 kVA models: 3,798 @ 208V and 220V input 6,294 @ 480V and 600V (with input isolation transformer)15 kVA models: 5,122 @ 208V and 220V input 8,134 @ 480V and 600V (with input isolation transformer)	20 kVA models: 6,762 @ 208V and 220V input 10,450 @ 480V and 600V (with input isolation transformer)30 kVA models: 9,220 @ 208V and 220V input 13,831 @ 480V and 600V (with input isolation transformer)
BATTERY
BATTERY TYPE	9 Ah, sealed, lead-acid, maintenance-free
BATTERY RUNTIME	See product brochure
BATTERY MANAGEMENT	ABM technology
BATTERY REPLACEMENT	Field-replaceable
CHARGER	9355 (10 – 15 kVA): Default is 3.4A per battery string. Charger current is configurable from 0.5A to 25A per string with an overall maximum of 34A (limited by input current)	9355 (20 – 30 kVA): Default is 8A
START-ON-BATTERY	Allows start of UPS without utility input
COMMUNICATIONS
LCD DISPLAY	Graphical LCD with blue backlight
LEDS	(4) LEDs for notice and alarm
AUDIBLE ALARMS	Yes
COMMUNICATION PORTS	(1) RS-232, (1) relay contact, (1) REPO, (2) environmental input
COMMUNICATION SLOTS	(2) X-Slot communication bays
POWER MANAGEMENT SOFTWARE	Bundled software suite CD
ENVIRONMENTAL
OPERATING TEMPERATURE	50–104ºF (10–40ºC), 45ºC with 7.5% derating; Optimal battery performance: 77ºF (25ºC)
STORAGE TEMPERATURE	32–77ºF (0–25ºC); Recommended battery storage: 59–77ºF (15–25ºC)
RELATIVE HUMIDITY	9355 (10 – 15 kVA): 0–95%, non-condensing	9355 (20 – 30 kVA): 5–95%, non-condensing
AUDIBLE NOISE	9355 (10 – 15 kVA): <56 dBA at 1 meter (noiseless room) typical	9355 (20 – 30 kVA): <58 dBA at 1 meter depending on load
ALTITUDE	9355 (10 – 15 kVA): 9,843 ft. (3000m) without derating	9355 (20 – 30 kVA): <3000m
CERTIFICATIONS
SAFETY CERTIFICATIONS	UL1778 5^th Edition, CSA C22.2 No. 107.3-14, NOM-NYCE
EMC COMPLIANCE	47 CFR Part 15/ICES-003 Class A
QUALITY	ISO 9001:2015, ISO 14001:2004
SURGE	ANSI C62.41 Category B3, IEC 61000-4-5
MARKINGS	cULus, NOM-NYCE
POWER DISTRIBUTION MODULE WITH MECHANICAL BYPASS SWITCH	See product brochure
OPTIONS	See product brochure
BUILT-IN CONNECTIVITY OPTIONS	See product brochure

Category: Eaton Datacentre

Description

Eaton 9355 UPS

The Eaton 9355 UPS (formerly the Powerware 9355) is a three-phase, double-conversion online UPS that provides a complete power protection solution. In a footprint that is up to 75 percent smaller than comparable UPSs, the 9355 UPS comes complete with internal batteries, an integrated power distribution module, and a maintenance bypass switch. Without the need for large external battery cabinets, it is possible to parallel up to four UPSs to build out redundancy or add capacity with less space than a typical large UPS requires, thanks to Eaton’s patented HotSync paralleling technology.

POWER RATING

10-30 kVA

VOLTAGE

208/220/480/600 VAC

CONFIGURATION

Tower
